1、 The price do not include the cost of our engineer after sales.

2、 The price include the cost of coder.  Code dating will be based on the following numeric sequence:

1234567890 – Production date

Where:

1…9  – series of numbers which can be adjusted from 0-9

3、 The max length of pag is 400mm.

The max width of pag is 160mm

The max height is 60mm

4、  The machine should handle the film which has the following details

a) Laminate 30-50microns

b) Core diameter : 76 mm Internal

c) Roll width (MAX)      :  450 mm

d) Roll diameter  :   Maximum 350 mm

e) Roll weight     : 15Kg

The film frame shall have provision for mounting one roll mounting shafts.

5、 Machine power supply shall be 220Volts , 50 HZ , 4KW

      If different, Pls tell us, we can change

6、 Packing speed  Max180ps/min.

7、 The packing machine has two sets conveyor, one is for noodles, and one is for seasoning.

8、 Before in forming box, the two conveyor will converge, the seasoning is under the noodles, So even high speed, the seasonings don’t fall.

1.The autofeeder drived by two inverter motor and two servo motor.

2.2000mm length

3. running with packing machine speed.

4. the three belts make the noodles one by one, and the last belt run faster speed, transport the noodles to between the pusher of packing.

5. the auto feeder controlled by one PLC.

6. 220V 1.6KW.

Appeal point:

1、The packing machine is driver by three motors, one servo motor drives film and long sealer, one drives end sealer and one drive the pusher conveyor.

2、PLC+HMI components. Bi-lingual (Chinese and English) instructions. Packing speed, length, temperature, control method can by chosen through HMI by numbers.

3、Double tracking method. Photo-sensor working together with servo system can realize automatic controlling according to the color code on the film, to make sure the cutting accuracy.

4、Safety alert and failure alert will be shown on HMI.

5、The design of the machine is a global standard appearance.

6、It can be connected to production lines of different capabilities to realize synchronism.

7、Compatible with multi film structures. The thinnest film can be 0.03mm;

8、The critical components of electrical system is Japanese made.

9、220V electrical heating system, accurate temperature contolling.

10、Color code detection system. Any errors on color code deviation, film misalignment and settings of photo-sensor switching can be shown.

11、Allocation of sealing jaw when stopping to eliminate melting problem of cross seal jaw and film when the machine is stopped.

12、Working platform and packing equipment are adjustable to pack multi dimension bags.

13、Customer can choose different knifes like straight line knife and wave line knife.
